SENSIT® VMD

SENSIT® VMD is a state-of-the-art vehicle mounted instrument used to detect, grade and map gas leaks along underground pipelines.

SENSIT® VMD is among the best performing and lowest cost optical instruments available today!

The instrument detects methane as low as 1ppm, per meter for real-time detection and logging with GPS data compatible with Google Earth.

Turn any vehicle with a front hitch into a survey instrument!

SENSIT® VMD is
Accurate
Durable
Easy to Use
Easy to Maintain

Description

Introduction

Leak Survey Detector, SENSIT® VMD, is a cutting-edge vehicle-mounted device. That is designed to detect, grade, and map gas leaks along underground pipelines. Its advanced features and capabilities make it one of the most sought-after optical devices on the market today. The VMD is highly effective and extremely affordable. Making it accessible to a wide range of users.

The SENSIT® VMD leak survey detector is equipped with a state-of-the-art detection mechanism. That can detect methane as low as 1ppm per meter. This means it can accurately detect gas leaks in real-time and log them with GPS data compatible with Google Earth.

The device is also capable of grading and mapping gas leaks. Making it easier for users to identify the severity of the leak and take appropriate action.

STANDARD FEATURES

One of the most significant advantages of the SENSIT® VMD device is that it can turn any vehicle with a front hitch into a leak survey detector. Installing the device is a breeze. And you can fit it onto any vehicle with a front mount receiver and 12 VDC power outlet/connection.

Once you install the device, you can use the leak survey detector to detect gas leaks in just a few minutes. Many users consider the SENSIT® VMD device as highly accurate, durable, and easy to use.

  • A Simple User Interface makes Operating it easy for Users
  • Adjustable Visual and Audible Alarms
  • Displays Gas Concentrations
  • System Status
  • GPS Location
  • Detection Alarms

Product Specification
Data Sheets
Product Specification

Product Specification

Product Specification

Size4 ft. and 5 ft. path length (5 ft. Standard)
Operating Temperature-22 to 122° F (-30 to 50° C)
Environmental ProtectionIP54
Power Requirement12-16 VDC / 60w
Standard Kit5 Ft. Survey Bar Assembly with Transmitter and Receiver
Tablet PC
Bluetooth Interface
GPS Interface
Calibration Cell

Optional Features

VMD Vehicle Mounting Kit
VMD Shield
PMD Vacuum Kit
PMD Vacuum System

Sensor Specifications

TypeResolutionRangeAccuracy
PPM* 0.1 PPM1.0-1000 PPM /Meter±10% 2PPM-M
